Comfort System Central Control Module -J393- Location

1. Comfort System Central Control Module -J393-

1. 17-Pin Connector -T17A- (Connector A), Brown
2. 32-Pin Connector -T32C- (Connector C), Black
3. 17-Pin Connector -T17B- (Connector B), Black
4. 20-Pin Connector -T20E- (Connector E), Black
5. 32-Pin Connector -T32D- (Connector D), Blue

Courtesy of AUDI OF AMERICA, LLC
