Power Windows: Description
System consists of an electrically operated tailgate window and individual motors at all side windows. Tailgate window operates on two circuits: an instrument panel switch or an external key switch at tailgate. Side windows are operated by individual switches at each door, or by a complete set of control switches at the instrument panel.
Electric tailgate window system consists of a safety switch, gearbox-type regulator, 12 volt DC motor, wiring and connections and a 30 amp. circuit breaker at fuse block. Electric side window system consists of regulator motors, switches, actuators and actuator rods, wiring and connections and a 30 amp. circuit breaker located at the fuse block.
