Code 32: EGR Sensor (CALIF.)

Fig 1: Code 32: EGR Sensor Test - California (1 of 3)

Courtesy of NISSAN MOTOR CO., U.S.A.

Fig 2: Code 32: EGR Sensor Test - California (2 of 3)

Courtesy of NISSAN MOTOR CO., U.S.A.

Fig 3: Code 32: EGR Sensor Test -California (3 of 3)

Courtesy of NISSAN MOTOR CO., U.S.A.
