ATF Cooler Hose Replacement

Connect the ATF cooler hoses (A) to the ATF filter (B), with the dot (C) facing up, and secure the hose ends with the clips (D).

Fig 1: Connecting ATF Cooler Hoses To ATF Filter With Dot Facing Up And Securing Hose Ends With Clips
Courtesy of AMERICAN HONDA MOTOR CO., INC.
Connect the ATF cooler hose (E) to the ATF cooler (F) with the dot (G) facing down, and to the ATF cooler lines (H) on the transmission, and secure the hoses with the clips.
Install the clamp on the hoses.
