'05-08 models

SRS components/are located in this area. Review the SRS component location index (see COMPONENT LOCATION INDEX ) and \precautions and procedures (see PRECAUTIONS AND PROCEDURES ) in the SRS before testing the solenoid.

1. Remove the driver's airbag (see DRIVER'S AIRBAG REPLACEMENT ).
   Fig 1: Identifying Driver's Airbag Switch Connector Terminals

   Courtesy of AMERICAN HONDA MOTOR CO., INC.
2. Check for continuity between the terminals according to the table.
   • If there is continuity, and it matches the table, but switch failure occurred on the cruise control input test, check and repair the wire harness on the switch circuit.
   • If there is no continuity in one or both positions, replace the switch.

   Without navigation

   Fig 2: Checking For Continuity Between Terminals Without Navigation

   Courtesy of AMERICAN HONDA MOTOR CO., INC.

   With navigation

   Fig 3: Checking For Continuity Between Terminals With Navigation

   Courtesy of AMERICAN HONDA MOTOR CO., INC.
