Repair Procedure: Notes

NOTE:

Review the Conventional Brake Service Precautions before doing repairs or service .
To prevent spills, cover the brake line joints with clean rags or shop towels.

Fig 1: Master Cylinder Area Replacement Components With Torque Specifications (1 Of 2)

Courtesy of HONDA, U.S.A., INC.

: Torque, N.m (lbf.ft)

: Replace

: Warning/Caution

: Inspection/Adjustment

*: Learning

■: SPL Tool

: Required Removal

Fig 2: Master Cylinder Area Replacement Components With Torque Specifications (2 Of 2)

Courtesy of HONDA, U.S.A., INC.

: Torque, N.m (lbf.ft)	: Replace	: Warning/Caution	: Inspection/Adjustment	*: Learning	■: SPL Tool	: Required Removal
*1: Mexico models
