Inspection Outline
- The components to be tested are indicated by a dotted line.
| Inspection Items | Work Items | |
|---|---|---|
| a | External Circuit | +B_SMART, IGN_TRX, GND Circuit Inspection |
| b | Electric Steering Lock | Electric Steering Lock Inspection |
| c | Body Control Module | Body Control Module Inspection |
