Temperature Setting
To maintain a constant air/fuel ratio at changing ambient air temperatures, a temperature compensator is installed on fuel injection pump. Set lever (see Figure) to correct position as follows:
| Temperature | Setting |
|---|---|
| Above 59°F | "N" (Normal) |
| 32-59°F | "C" (Cold) |
| Below 32°F | "F" (Freezing) |
