Switch - Passenger Front

REMOVAL

1. Disconnect and isolate the negative battery cable.

   Courtesy of CHRYSLER GROUP, LLC

2. Using a trim stick or suitable tool, lift up the power window switch (1a) and release the retainers (1b).
3. Disconnect the wiring harness connectors (2a) from the power window switch.
4. Remove the power window switch (1a) from the vehicle.

INSTALLATION

1. Position the power switch unit (1b) to the door panel for installation.

   Courtesy of CHRYSLER GROUP, LLC

2. Connect the wiring harness connector (1a) to the power window switch (1b).
3. Install the power window switch and secure the retainers (2a).
4. Connect the negative battery cable.
