Installation & Adjustment

To install, reverse removal procedure, then perform adjustment as follows: Bolt steering assembly to outer steering tube. Attach gear to crossmember, but do not tighten bolts. Loosen upper control arm mounting bolts on both sides and install special steering gauge 41-102 so that gauge rests firmly on upper control arm. Turn rack until it rests on ruler of gauge. Adjust other side in same manner and tighten mounting bolts to 18 ft.lbs. (2.5 mkg). See Figure .
