Engine Cooling Fan: Description

All models are equipped with an electronic cooling fan. The cooling fan is operated by a thermoswitch in response to engine temperature. Thermoswitch is located on coolant pipe behind right cylinder head. See Fig 1 .

Fig 1: Locating Electric Cooling Fan Components (Cabriolet)

Courtesy of AUDI OF AMERICA, INC.
