Vehicle Electrical System Control Module 2 Connector End View (J520, T40)

Fig 1: Vehicle Electrical System Control Module 2 Connector End View (J520, T40)

Courtesy of AUDI OF AMERICA, LLC

A	Vehicle Electrical System Control Module 2 -J520- Connector
B	40-Pin Connector, black -T40-
