Wiper Motor Control Module -J400-, Connector Views

1. 4-Pin Connector -T4t-

Courtesy of AUDI OF AMERICA, LLC

T4t (B)	Designation
1	Terminal 30, from Fuse Panel B SB
2	Terminal 31, to 369 Ground Connection 4 (in main wiring harness) 44 Ground Connection (on left lower A-pillar)
3
4	LIN-Bus, from Vehicle Electrical System Control Module J519
