Engine Control Module (ECM) -J623-, Location, 154-Pin, RHD

  1. Engine Control Module (ECM) -J623-
  2. 60-Pin Connector -T60-, black
  3. 94-Pin Connector -T94-, black
G12768111Courtesy of AUDI OF AMERICA, LLC
