Steering Overview

  1. 3 - Power steering control module J500
  2. 3 - Electromechanical power steering motor -V187-
    • Steering torque sensor -G269-
      • Located on the rack input shaft - lower.
G12770237Courtesy of AUDI OF AMERICA, LLC
