Front, View From Front

1. 5-Pin Connector -T5am-, black/5-Pin Connector -T5amx-, black
2. 14-Pin Connector -T14n-, black/14-Pin Connector -T14nx-, black

1. Right Front Parallel Parking Assistance Sensor, right model side -G569-
2. Right Front Parking Aid Sensor -G252-
3. Front Right Headlamp -MX2-
4. High Tone Horn -H2-
5. Front Peripheral Camera -R243-
6. Front Left Headlamp -MX1-
7. Left Front Parking Aid Sensor -G255-
8. Left Front Parallel Parking Assistance Sensor, left model side -G568-
9. Low Tone Horn -H7-
10. Left Front Center Parking Aid Sensor -G254-
11. Outside Air Temperature Sensor -G17-
12. Distance Regulation Control Module -J428-
13. Right Front Center Parking Aid Sensor -G253-

Courtesy of AUDI OF AMERICA, LLC
