Horn Control: Installation

To install, reverse removal procedure and note the following: Check size of steering wheel nut before tightening. Torque a 0.47" (12 mm) nut to 40-43 ft. lbs. (5.5-6.0 mkg), and a 0.55" (14 mm) nut to 61-69 ft. lbs. (8.5-9.5 mkg).

Fig 1: Column Switch Plate (6 Cyl. Shown)
G09355761Courtesy of BMW OF NORTH AMERICA, INC.
