IHKA Climate Control System (E39): Introduction: Notes
The E39 IHKA follows the IHKA E38 system and provides features and functions similar to that unit. It incorporates the following features:
- Integrated control panel/module.
- Separate temperature control for the driver and front passenger.
- Air flap control through the use of bussed stepper motors.
- Automatic Recirculation Control (AUC).
- Recirculation air flap control from the MFL.
- "REST" function for residual heat when vehicle is stopped.
- Service station feature that closes the water valves when stopped to prevent hot water circulating into the heater cores.
- A/C compressor clutch activation through a final stage control.
- Center face vent stratification control through a bowden cable.
