OBD & Network Connection

OBD connection (2)
DK LAN connection (1)
2 color LED (4)

Green- flashing OPPS is free,
Green solid OPPS is connected.
Green rapid flash Software update active
Orange self test active or fault

External voltage testing (3)

Fig 1: Identifying OBD & Network Connection
Courtesy of BMW OF NORTH AMERICA, INC.
