Adaptive Headlight Control: Notes

In conjunction with the Bi-Xenon headlights an Adaptive Headlight control system is also included on the E90.

The function of the Adaptive Headlight Control system is to provide an enhanced lighting path as the vehicle travels through a turn, plus reduce the risk of excessive glare to on coming traffic. The adaptive headlight control allows the headlights to rotate slightly as the front wheels turn.

Fig 1: Identifying Components Control Modules Adaptive Headlight Control

Courtesy of BMW OF NORTH AMERICA, INC.
