License Plate Light

The license plate light is designed based on LEDs. The LEDs are integrated in the strip handle on the luggage compartment lid. Three LEDs are used for each license plate light.

Fig 1: Identifying Left And Right License Plate Light With Trunk Release Button

Courtesy of BMW OF NORTH AMERICA, INC.

COMPONENTS DESCRIPTION CHART

Index	Explanation
1	L and R License plate lights
2	Trunk release button
