86 10... Disassembly of front apron: Notes

Drill out rivets (1) on lower apron edge.

Fig 1: Identifying Rivets On Lower Apron Edge

Courtesy of BMW OF NORTH AMERICA, INC.

Remove sealing compound (1).

Drill out rivets (2).
