Body Control System Connector End Views

WARNING: This page is about a different car, the 2003 Buick Park Avenue. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Body Control Module C1

Courtesy of GENERAL MOTORS CORP.

Fig 2: Body Control Module C2

Courtesy of GENERAL MOTORS CORP.
