Traction Control Switch Replacement

Fig 1: Driver Information Center Switch

Courtesy of GENERAL MOTORS CORP.

Traction Control Switch Replacement

Callout	Component Name
Fastener Tightening Specifications:  Refer to Fastener Tightening Specifications .
1	Bezel, Driver Information Display Tip:  Pull the bezel away from the instrument panel far enough to disconnect the electrical connectors, then remove the bezel from the vehicle.
3	Switch Assembly, Driver Information Display
