Electronic Suspension Control Module Replacement

WARNING: This page is about a different car, the 2011 Buick Regal. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Electronic Suspension Control Module

Courtesy of GENERAL MOTORS CORP.

Callout	Component Name
Preliminary Procedure: Remove the left side luggage compartment trim. Refer to Rear Compartment Side Trim Panel Replacement .
1	Electronic Suspension Front Position Sensor Fastener (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten: 9 N.m(80 lb in)
2	Electronic Suspension Control Module Console Procedure: Remove the bracket from the control module. Slide the control module down from the bracket.
3	Electronic Suspension Control Module Procedure Disconnect the connectors. For programming and setup information, refer to Control Module References .
