Multimedia Player Interface Module Replacement

Fig 1: Communication Interface Module

Courtesy of GENERAL MOTORS COMPANY

Callout	Component Name
Preliminary Procedure Instrument Panel Compartment Replacement .
1	Multimedia Player Interface Module Procedure Disconnect the electrical connector. Navigation Signal Splitter Replacement »Remove Control Module References »Programming and Setup

Callout

Component Name

Multimedia Player Interface Module

Procedure
