Power Transfer Unit Heat Shield Replacement

Courtesy of GENERAL MOTORS COMPANY

Callout	Component Name
Preliminary Procedure  Remove the three-way catalytic converter. Three-Way Catalytic Converter Replacement (Bank 1) , or Three-Way Catalytic Converter Replacement (Bank 2)
1	Transfer Case Heat Shield Fasteners [3x]
2	Transfer Case Heat Shield
