Note On Intermittents

Manipulate power steering pressure switch connector with engine running. If intermittent is created, code will set. Disconnect and reconnect power steering connector to ensure they are properly latched.

Fig 1: ECM Code EO40 Circuit Diagram
G90A21733
Fig 2: ECM Code EO40 Flow Chart
G90B13715
