Connector Terminal Identification
›
Lighting Systems
›
Turn Signal Switch
Turn Signal Switch
Fig 1: Turn Signal Switch - 9-Pin Connector
Courtesy of GENERAL MOTORS CORP.
Courtesy of GENERAL MOTORS CORP.
