Connector Identification

Fig 1: Identifying A/T Shift Lever Connector Terminals

Courtesy of GENERAL MOTORS CORP.

Fig 2: Identifying Stoplamp Switch Connector Terminals

Courtesy of GENERAL MOTORS CORP.
