Left Rear Fuse Block

Left rear fuse block is located in the passenger compartment, under the left side of the rear seat. See Fig 1.

Fig 1: Locating Left Rear & Right Rear Fuse Blocks

Courtesy of GENERAL MOTORS CORP.

Fig 2: Identifying Left Rear Fuse Block Components & Legend

Courtesy of GENERAL MOTORS CORP.

LEFT REAR FUSE BLOCK RELAY IDENTIFICATION

RELAY DESCRIPTION
L Position relay
R Position Relay
IGN 3 Relay
Pusher Fan Relay
Reverse Lamp Relay
Trunk Door Release Solenoid Relay
Standing Lamp Relay
