Removal Procedure

WARNING: This page does not describe the selected car, but rather 6 other vehicles, including the 2003 GMC Savana Special, 2003 GMC Savana Camper Special, 2003 GMC Savana, 2003 Chevrolet RV Cutaway, and 2003 Chevrolet Cutaway. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the retainer at the top of the side front door weatherstrip.
  2. Remove the side front door weatherstrip from the top of the door. Use 3M Release Agent or the equivalent.
  3. Pull the side front door weatherstrip in order to remove the weatherstrip from the channel on the side of the door.
  4. Remove the side front door weatherstrip and the retainers from the bottom of the door.
  5. Clean the door of all of the old adhesive.
    Fig 1: Removing Side Front Door Weatherstrip
    G02423229Courtesy of GENERAL MOTORS CORP.
