Instrument Panel Integration Module (IPM) Connector End View C1

Fig 1: Instrument Panel Integration Module (IPM) C1 (1 Of 2)

Courtesy of GENERAL MOTORS CORP.

Fig 2: Instrument Panel Integration Module (IPM) C1 (2 Of 2)

Courtesy of GENERAL MOTORS CORP.
