Stationary Windows Component Views

Fig 1: Passenger Compartment, Windshield Component View

Courtesy of GENERAL MOTORS CORP.

Callout	Component Name
1	S309
2	Outside Moisture Sensor
3	Outside Moisture Sensor Cover
4	Inside Rearview Mirror
