Removal Procedure

WARNING: This page is about a different car, the 2009 GMC Sierra, 2009 GMC Cab & Chassis Sierra, 2009 Chevrolet Silverado, and 2009 Chevrolet Cab & Chassis Silverado. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the upper fan shroud. Refer to Engine Coolant Fan Upper Shroud Replacement (LMM Diesel)  or Engine Coolant Fan Upper Shroud Replacement (Mechanical) .
    2. Fig 1: Identifying Fan Shroud Mounting Brackets & Bolts
    GM1674565Courtesy of GENERAL MOTORS CORP.
  2. Remove the 3 engine cooling fan shroud bolts (1).
    3. Fig 2: View Of Cooling Fan Shroud
    GM1674593Courtesy of GENERAL MOTORS CORP.
  3. Position the engine cooling fan shroud (1) forward to the radiator.
    4. Fig 3: View Of Fan Clutch Hub & Nut
    GM1674552Courtesy of GENERAL MOTORS CORP.
  4. Install a long pin bar into the fan hub (1).
  5. Use a J 46406  to remove the fan hub nut (2) from the hub in a counterclockwise rotation. See Special Tools .
  6. Remove the fan and the engine cooling fan shroud as an assembly.
    7. Fig 4: View Of Fan Clutch & Fan Blade
    GM367006Courtesy of GENERAL MOTORS CORP.
  7. Separate fan and shroud.
  8. Remove the fan clutch bolts from the rear of the fan blade.
  9. Separate the fan clutch from the fan blade.
