Installation Procedure

WARNING: This page does not describe the selected car, but rather 6 other vehicles, including the 2003 GMC Savana Special, 2003 GMC Savana Camper Special, 2003 GMC Savana, 2003 Chevrolet RV Cutaway, and 2003 Chevrolet Cutaway. However, it is still accessible from the selected car via links, so may be relevant.

Important: Ensure that the engine cover sealing strip is properly seated between the engine cover and the vehicle.

Install the engine cover to the vehicle (2).
Install the engine cover retainers (1, 3).

Fig 1: Installing Engine Cover

Courtesy of GENERAL MOTORS CORP.

Install the left knee bolster. Refer to KNEE BOLSTER REPLACEMENT - LEFT .
Install the right knee bolster. Refer to KNEE BOLSTER REPLACEMENT - RIGHT .
Install the instrument panel lower extension, if equipped. Refer to INSTRUMENT PANEL (I/P) EXTENSION REPLACEMENT .
Install the front passenger seat. Refer to SEAT REPLACEMENT .
