Fastener Specifications

GM5484187Courtesy of GENERAL MOTORS COMPANY
Accelerator Pedal

Callout Component Name [Component Quantity] Single Use Fastener/Component Thread Locking Adhesive Required Specification Procedure
Metric (English)
1 Accelerator Pedal Bracket Bolt - - 9 N.m (80 lb in) Accelerator Pedal Replacement
GM5862959Courtesy of GENERAL MOTORS COMPANY
Air Cleaner Assembly

Callout Component Name [Component Quantity] Single Use Fastener/Component Thread Locking Adhesive Required Specification Procedure
Metric (English)
1 Air Cleaner Bolt - - 9 N.m (80 lb in) Air Cleaner Assembly Replacement
GM5841337Courtesy of GENERAL MOTORS COMPANY
Air Cleaner Element

Callout Component Name [Component Quantity] Single Use Fastener/Component Thread Locking Adhesive Required Specification Procedure
Metric (English)
1 Air Cleaner Housing Cover Bolt [13x] - - 2 N.m (18 lb in) Air Cleaner Element Replacement
GM5841344Courtesy of GENERAL MOTORS COMPANY
Air Cleaner Outlet Ducts and Mass Airflow Sensors

Callout Component Name [Component Quantity] Single Use Fastener/Component Thread Locking Adhesive Required Specification Procedure
Metric (English)
1 Air Cleaner Outlet Duct Clamp - - 4 N.m (35 lb in) Air Cleaner Outlet Duct Replacement
2 Mass Airflow Sensor Bolt [2x] - - 1.8 N.m (16 lb in) Mass Airflow Sensor Replacement - Right Side
3 Mass Airflow Sensor Bolt [2x] - - 1.8 N.m (16 lb in) Mass Airflow Sensor Replacement - Left Side
4 Air Cleaner Outlet Duct Clamp - - 4 N.m (35 lb in) Auxiliary Air Cleaner Outlet Duct Replacement
GM5843996Courtesy of GENERAL MOTORS COMPANY
Air Cleaner Outlet Resonator Bracket

Callout Component Name [Component Quantity] Single Use Fastener/Component Thread Locking Adhesive Required Specification Procedure
Metric (English)
1 Air Cleaner Outlet Duct Bracket Bolt [2x] - - 9 N.m (80 lb in) Air Cleaner Outlet Resonator Bracket Replacement
GM5892438Courtesy of GENERAL MOTORS COMPANY
Charge Air Bypass Valve Replacement Front - Positions 1 and 2

Callout Component Name [Component Quantity] Single Use Fastener/Component Thread Locking Adhesive Required Specification Procedure
Metric (English)
1 Charge Air Bypass Valve Vacuum Tank Bolt - - 10 N.m (89 lb in) Charge Air Bypass Valve Replacement - Position 1 Front
2 Charge Air Bypass Valve Vacuum Tank Bolt - - 10 N.m (89 lb in) Charge Air Bypass Valve Replacement - Position 2 Front
GM5892530Courtesy of GENERAL MOTORS COMPANY
Charge Air Bypass Valve Replacement Rear (Positions 1 and 2)

Callout Component Name [Component Quantity] Single Use Fastener/Component Thread Locking Adhesive Required Specification Procedure
Metric (English)
1 Charge Air Bypass Valve Hose Clamp [2x] - - 3.5 N.m (31 lb in) Charge Air Bypass Valve Replacement - Position 1 Rear
2 Charge Air Bypass Valve Tube Connector Clamp [2x] - - 3.5 N.m (31 lb in) Charge Air Bypass Valve Replacement - Position 2 Rear
GM5921103Courtesy of GENERAL MOTORS COMPANY
Charge Air Cooler Inlet Air Hose - Right Side

Callout Component Name [Component Quantity] Single Use Fastener/Component Thread Locking Adhesive Required Specification Procedure
Metric (English)
1 Charge Air Cooler Inlet Air Hose Clamp - - 5 N.m (44 lb in) Charge Air Cooler Inlet Air Hose Replacement - Right Side
GM5921111Courtesy of GENERAL MOTORS COMPANY
Charge Air Cooler Inlet Air Hose - Left Side

Callout Component Name [Component Quantity] Single Use Fastener/Component Thread Locking Adhesive Required Specification Procedure
Metric (English)
1 Charge Air Cooler Inlet Air Hose Clamp - - 5 N.m (44 lb in) Charge Air Cooler Inlet Air Hose Replacement - Left Side
GM5890658Courtesy of GENERAL MOTORS COMPANY
Crankshaft Position Sensor Shield

Callout Component Name [Component Quantity] Single Use Fastener/Component Thread Locking Adhesive Required Specification Procedure
Metric (English)
1 Crankshaft Position Sensor Bolt - - 10 N.m (89 lb in) Crankshaft Position Sensor Replacement
2 Crankshaft Position Sensor Shield Bolt [2x] - - 9 N.m (80 lb in) Crankshaft Position Sensor Shield Replacement
GM5841343Courtesy of GENERAL MOTORS COMPANY
Engine Control Module Bracket

Callout Component Name [Component Quantity] Single Use Fastener/Component Thread Locking Adhesive Required Specification Procedure
Metric (English)
1 Engine Control Module Bracket Bolt [3x] - - 9 N.m (80 lb in) Engine Control Module Bracket Replacement
GM5874528Courtesy of GENERAL MOTORS COMPANY
Front Engine Sensors and Turbocharger Wastegate Regulator Solenoid Valves

Callout Component Name [Component Quantity] Single Use Fastener/Component Thread Locking Adhesive Required Specification Procedure
Metric (English)
1 Intake Air Pressure and Temperature Sensor Bolt - - 10 N.m (89 lb in) Intake Air Pressure and Temperature Sensor Replacement
2 Turbocharger Wastegate Actuator Vacuum Tank Bolt [2x] - - 9 N.m (80 lb in) Turbocharger Wastegate Regulator Solenoid Valve Replacement - Bank 1
3 Turbocharger Wastegate Actuator Vacuum Tank Bolt [2x] - - 9 N.m (80 lb in) Turbocharger Wastegate Regulator Solenoid Valve Replacement - Bank 2
4 Camshaft Position Actuator Solenoid Valve Bolt - - 10 N.m (89 lb in) Camshaft Position Actuator Valve Solenoid Replacement - Bank 1 (Right Side) Intake
5 Camshaft Position Sensor Bolt - - 10 N.m (89 lb in) Camshaft Position Sensor Replacement - Bank 2 (Left Side) Exhaust
6 Camshaft Position Actuator Solenoid Valve Bolt - - 10 N.m (89 lb in) Camshaft Position Actuator Valve Solenoid Replacement - Bank 1 (Right Side) Exhaust
7 Camshaft Position Sensor Bolt - - 10 N.m (89 lb in) Camshaft Position Sensor Replacement - Bank 2 (Left Side) Intake
8 Camshaft Position Sensor Bolt - - 10 N.m (89 lb in) Camshaft Position Sensor Replacement - Bank 1 (Right Side) Exhaust
9 Camshaft Position Actuator Solenoid Valve Bolt - - 10 N.m (89 lb in) Camshaft Position Actuator Valve Solenoid Replacement - Bank 2 (Left Side) Intake
10 Camshaft Position Sensor Bolt - - 10 N.m (89 lb in) Camshaft Position Sensor Replacement - Bank 1 (Right Side) Intake
11 Camshaft Position Actuator Solenoid Valve Bolt - - 10 N.m (89 lb in) Camshaft Position Actuator Valve Solenoid Replacement - Bank 2 (Left Side) Exhaust
12 Evaporative Emission Canister Purge Solenoid Valve Bracket Bolt - - 10 N.m (89 lb in) Evaporative Emission Canister Purge Solenoid Valve Replacement
13 Tie Strap Yes - - Evaporative Emission Canister Purge Solenoid Valve Replacement
GM5890326Courtesy of GENERAL MOTORS COMPANY
Fuel Feed Pipe

Callout Component Name [Component Quantity] Single Use Fastener/Component Thread Locking Adhesive Required Specification Procedure
Metric (English)
1 Fuel Injection Fuel Feed and Return Pipe Retainer Bolt [2x] - - 50 N.m (37 lb ft) Fuel Feed Pipe Replacement
2 Fuel Feed Pipe Yes - - Fuel Feed Pipe Replacement
GM5874889Courtesy of GENERAL MOTORS COMPANY
Fuel Pipe Shield

Callout Component Name [Component Quantity] Single Use Fastener/Component Thread Locking Adhesive Required Specification Procedure
Metric (English)
1 Engine Rear Noise Shield Bolt [3x] - - 9 N.m (80 lb in) Fuel Pipe Shield Replacement
GM5873941Courtesy of GENERAL MOTORS COMPANY
Fuel Pump

Callout Component Name [Component Quantity] Single Use Fastener/Component Thread Locking Adhesive Required Specification Procedure
Metric (English)
1 Fuel Pump Bolt [2x] - - 15 N.m (11 lb ft) Fuel Pump Replacement
2 Fuel Pump Bracket Gasket Yes - - Fuel Pump Replacement
3 Fuel Pump Housing Seal Yes - - Fuel Pump Replacement
GM5890241Courtesy of GENERAL MOTORS COMPANY
Fuel Rail and Fuel Injector Components

Callout Component Name [Component Quantity] Single Use Fastener/Component Thread Locking Adhesive Required Specification Procedure
Metric (English)
1 Fuel Injection Fuel Rail Bolt [8x] - Yes 25 N.m (18 lb ft) Fuel Injection Fuel Rail Assembly Replacement - Bank 1
Fuel Injection Fuel Rail Assembly Replacement - Bank 2
2 Tie Strap Yes - - Fuel Injection Fuel Rail Assembly Replacement - Bank 1
3 Fuel Rail Pressure Sensor - - 32.5 N.m (24 lb ft) Fuel Rail Pressure Sensor Replacement
4 Fuel Injection Fuel Rail Seal Yes - - Fuel Injector Replacement - Bank 1
Fuel Injector Replacement - Bank 2
5 Fuel Injector Retainer Yes - - Fuel Injector Replacement - Bank 1
Fuel Injector Replacement - Bank 2
6 Fuel Injector Nozzle Housing Seal Yes - - Fuel Injector Replacement - Bank 1
Fuel Injector Replacement - Bank 2
GM5840793Courtesy of GENERAL MOTORS COMPANY
Fuel Tank and Components

Callout Component Name [Component Quantity] Single Use Fastener/Component Thread Locking Adhesive Required Specification Procedure
Metric (English)
1 Fuel Tank Filler Pipe Ground Bolt [2x] - - 9 N.m (80 lb in) Fuel Tank Filler Pipe Replacement
2 Evaporative Emission Canister Filter Hose Strap Yes - - Evaporative Emission Canister Air Inlet Hose Replacement
3 Evaporative Emission Canister Filter Hose Strap [4x] Yes - - Evaporative Emission Canister Purge Hose Replacement
Fuel Tank Vent Hose Replacement
4 Fuel Pump Power Control Module Nut [3x] - - 9 N.m (80 lb in) Fuel Pump Power Control Module Replacement
5 Fuel Tank Filler Hose Clamp [2x] - - 3.5 N.m (31 lb in) Fuel Tank Filler Hose Replacement
6 Fuel Pump Seal Yes - - Fuel Tank Fuel Pump Module Replacement (MG9) , or Fuel Tank Fuel Pump Module Replacement (MHU)
7 Fuel Tank Strap Bolt [5x] - - 22 N.m (16 lb ft) Fuel Tank Replacement (MG9) , or Fuel Tank Replacement (MHU)
GM5873872Courtesy of GENERAL MOTORS COMPANY
Heated Oxygen Sensors

Callout Component Name [Component Quantity] Single Use Fastener/Component Thread Locking Adhesive Required Specification Procedure
Metric (English)
1 Heated Oxygen Sensor - - 42 N.m (31 lb ft) Heated Oxygen Sensor Replacement - Bank 1 Sensor 1
2 Heated Oxygen Sensor - - 42 N.m (31 lb ft) Heated Oxygen Sensor Replacement - Bank 1 Sensor 2
3 Heated Oxygen Sensor - - 42 N.m (31 lb ft) Heated Oxygen Sensor Replacement - Bank 2 Sensor 1
4 Heated Oxygen Sensor - - 42 N.m (31 lb ft) Heated Oxygen Sensor Replacement - Bank 2 Sensor 2
GM5874761Courtesy of GENERAL MOTORS COMPANY
Ignition Components

Callout Component Name [Component Quantity] Single Use Fastener/Component Thread Locking Adhesive Required Specification Procedure
Metric (English)
1 Gas Engine Ignition Spark Plug [3x] - - 18 N.m (13 lb ft) Gas Engine Ignition Spark Plug Replacement - Right Side
2 Ignition Coil Bolt [3x] - - 10 N.m (89 lb in) Ignition Coil Replacement - Bank 2
3 Ignition Coil Bolt [3x] - - 10 N.m (89 lb in) Ignition Coil Replacement - Bank 1
4 Gas Engine Ignition Spark Plug [3x] - - 18 N.m (13 lb ft) Gas Engine Ignition Spark Plug Replacement - Left Side
GM5890680Courtesy of GENERAL MOTORS COMPANY
Knock Sensors

Callout Component Name [Component Quantity] Single Use Fastener/Component Thread Locking Adhesive Required Specification Procedure
Metric (English)
1 Knock Sensor Bolt - - 25 N.m (18 lb ft) Knock Sensor Replacement - Bank 1
2 Knock Sensor Bolt - - 25 N.m (18 lb ft) Knock Sensor Replacement - Bank 2
GM5873930Courtesy of GENERAL MOTORS COMPANY
Rear Engine Sensors and Fuel Feed Intermediate Pipe

Callout Component Name [Component Quantity] Single Use Fastener/Component Thread Locking Adhesive Required Specification Procedure
Metric (English)
1 Manifold Absolute Pressure Sensor Bolt - - 10 N.m (89 lb in) Manifold Absolute Pressure Sensor Replacement
2 Fuel Feed Intermediate Pipe Nut [3x] Yes - 28 N.m (21 lb ft) Fuel Feed Intermediate Pipe Replacement
3 Engine Coolant Thermostat Housing Bolt [2x] - - 10 N.m (89 lb in) Engine Coolant Temperature Sensor Replacement
4 Fuel Rail Pressure Sensor - - 32.5 N.m (24 lb ft) Fuel Rail Pressure Sensor Replacement
GM5890308Courtesy of GENERAL MOTORS COMPANY
Throttle Body Assembly

Callout Component Name [Component Quantity] Single Use Fastener/Component Thread Locking Adhesive Required Specification Procedure
Metric (English)
1 Throttle Body Bolt [4x] - - 10 N.m (89 lb in) Throttle Body Assembly Replacement
2 Throttle Body Gasket Yes - - Throttle Body Assembly Replacement
GM5890336Courtesy of GENERAL MOTORS COMPANY
Turbocharger Air Inlet Adapter - Bank 1

Callout Component Name [Component Quantity] Single Use Fastener/Component Thread Locking Adhesive Required Specification Procedure
Metric (English)
1 Turbocharger Air Inlet Adapter Bolt [3x] - - 10 N.m (89 lb in) Turbocharger Air Inlet Adapter Replacement - Bank 1
2 Turbocharger Air Inlet Adapter Seal Yes - - Turbocharger Air Inlet Adapter Replacement - Bank 1
GM5890346Courtesy of GENERAL MOTORS COMPANY
Turbocharger Air Inlet Adapter - Bank 2

Callout Component Name [Component Quantity] Single Use Fastener/Component Thread Locking Adhesive Required Specification Procedure
Metric (English)
1 Turbocharger Air Inlet Adapter Bolt [3x] - - 10 N.m (89 lb in) Turbocharger Air Inlet Adapter Replacement - Bank 1
2 Turbocharger Air Inlet Adapter Seal Yes - - Turbocharger Air Inlet Adapter Replacement - Bank 1
GM5890387Courtesy of GENERAL MOTORS COMPANY
Turbocharger Wastegate Actuator - Right Side

Callout Component Name [Component Quantity] Single Use Fastener/Component Thread Locking Adhesive Required Specification Procedure
Metric (English)
1 Turbocharger Wastegate Actuator Bolt [2x] - - - Turbocharger Wastegate Actuator Replacement - Right Side
GM5890519Courtesy of GENERAL MOTORS COMPANY
Turbocharger Wastegate Actuator - Left Side

Callout Component Name [Component Quantity] Single Use Fastener/Component Thread Locking Adhesive Required Specification Procedure
Metric (English)
1 Turbocharger Wastegate Actuator Bolt [2x] - - - Turbocharger Wastegate Actuator Replacement - Left Side
GM5874881Courtesy of GENERAL MOTORS COMPANY
Turbocharger Wastegate Actuator Vacuum Tank and Charge Air Cooler Components

Callout Component Name [Component Quantity] Single Use Fastener/Component Thread Locking Adhesive Required Specification Procedure
Metric (English)
1 Charge Air Cooler Inlet Air Tube Bolt [2x] - - 9 N.m (80 lb in) Charge Air Cooler Inlet Air Hose Replacement - Right Side
2 Charge Air Cooler Inlet Air Tube Seal Yes - - Charge Air Cooler Inlet Air Hose Replacement - Right Side
3 Charge Air Bypass Valve Hose Clamp - - 3.5 N.m (31 lb in) Charge Air Bypass Valve Replacement - Position 1 Rear
4 Charge Air Bypass Valve Tube Connector Clamp - - 3.5 N.m (31 lb in) Charge Air Bypass Valve Replacement - Position 1 Rear
5 Charge Air Bypass Valve Tube Connector Clamp - - 5 N.m (44 lb in) Charge Air Bypass Valve Replacement - Position 2 Rear
6 Charge Air Bypass Valve Hose Clamp - - 3.5 N.m (31 lb in) Charge Air Bypass Valve Replacement - Position 2 Rear
7 Charge Air Cooler Inlet Air Tube Seal Yes - - Charge Air Cooler Inlet Air Hose Replacement - Left Side
8 Charge Air Cooler Inlet Air Tube Bolt [2x] - - 9 N.m (80 lb in) Charge Air Cooler Inlet Air Hose Replacement - Left Side
9 Charge Air Bypass Valve Tube Connector Clamp - - 5 N.m (44 lb in) Charge Air Cooler Inlet Air Hose Replacement - Left Side
10 Charge Air Bypass Valve Hose Clamp - - 3.5 N.m (31 lb in) Charge Air Bypass Valve Hose Replacement - Right Side
11 Turbocharger Wastegate Actuator Vacuum Tank Bolt [2x] - - 9 N.m (80 lb in) Turbocharger Wastegate Actuator Vacuum Tank Replacement
12 Charge Air Bypass Valve Hose Clamp - - 3.5 N.m (31 lb in) Charge Air Bypass Valve Hose Replacement - Right Side
13 Charge Air Bypass Valve Tube Connector Clamp - - 5 N.m (44 lb in) Charge Air Cooler Inlet Air Hose Replacement - Right Side
GM5892316Courtesy of GENERAL MOTORS COMPANY
Vacuum Pump Replacement

Callout Component Name [Component Quantity] Single Use Fastener/Component Thread Locking Adhesive Required Specification Procedure
Metric (English)
1 Vacuum Pump Bolt [2x] - - 10 N.m (89 lb in) Vacuum Pump Replacement
