Circuit Protection Devices
CIRCUIT PROTECTION DEVICES LOCATION
| Component | Location |
|---|---|
| In-Line Fuse | On engine harness, near underhood fuse/relay center. |
| I/P Fuse Block (4.3L VIN W) | On left lower kick panel. See Figure . |
| I/P Fuse Block (5.0L VIN M & 5.7L VIN R) | On left lower kick panel. See Figure . |
| I/P Fuse Block (6.5L VIN F) | On left lower kick panel. See Figure . |
| I/P Fuse Block (7.4L VIN J) | On left lower kick panel. See Figure . |
| I/P Relay Center | Under left side of dash. |
| Underhood Fuse/Relay Center (4.3L VIN W) | On left side of engine compartment. See Figure . |
| Underhood Fuse/Relay Center (5.0L VIN M & 5.7L VIN R) | On left side of engine compartment. See Figure . |
| Underhood Fuse/Relay Center (6.5L VIN F) | On left rear of engine compartment, on fender. |
| Underhood Fuse/Relay Center (7.4L VIN J) | On left side of engine compartment. See Figure . |
