Test E: Liftgate Window Release Is Inoperative With Transmitter

To perform test, see Fig 1 .

Fig 1: Test E: Liftgate Window Release Is Inoperative With Transmitter

G00125766

Courtesy of GENERAL MOTORS CORP.
