Installation Procedure

Install the speedometer (2) to the instrument cluster case.

Fig 1: Installing Speedometer
Courtesy of GENERAL MOTORS CORP.
Secure the speedometer with the 5 screws (2).
Install the instrument cluster retainer. Refer to BEZEL REPLACEMENT - IP Cluster .

Fig 2: Securing Speedometer With 5 Screws
Courtesy of GENERAL MOTORS CORP.
