Installation Procedure

Install the power steering fluid reservoir (2) to the vehicle.

Fig 1: Installing Power Steering Fluid Reservoir
Courtesy of GENERAL MOTORS CORP.

Important: Make sure that the alignment mark on the power steering return hose is installed at the bottom of the power steering reservoir.
Install the following components to the power steering fluid reservoir (2):
- The power steering reservoir outlet pipe/hose. Refer to POWER STEERING RESERVOIR OUTLET PIPE/HOSE REPLACEMENT .
- The power steering return hose. Refer to POWER STEERING RETURN HOSE REPLACEMENT .
Install the power steering fluid reservoir (2) to the power steering fluid reservoir bracket (5).
Bleed the power steering system. Refer to BLEEDING THE POWER STEERING SYSTEM .
