Engine Control System Self-Diagnostics - 3.8L
›
Diagnostic Tests
›
DTC P1670: Output Driver Module Circuit No. 4
›
Diagnostic Procedures
Diagnostic Procedures
Fig 1: DTC P1670: Output Driver Module Circuit No. 4
Courtesy of GENERAL MOTORS CORP.
