Engine Control System - Self-Diagnostics - 5.3L
›
Diagnostic Tests
›
DTC P0325: Knock Sensor Module Circuit
›
Diagnostic Procedure
Diagnostic Procedure
Fig 1: DTC P0325: Knock Sensor Module Circuit
Courtesy of GENERAL MOTORS CORP.
