Door Handle Replacement - Outside

Fig 1: Outside Door Handle

Courtesy of GENERAL MOTORS CORP.

Callout	Component Name
NOTE: Refer to Fastener Notice . Fastener Tightening Specifications: Refer to Fastener Tightening Specifications . Preliminary Procedures Remove the interior trim panel. Refer to Trim Panel Replacement - Door . Remove the water deflector. Refer to Water Deflector Replacement - Front Door .
1	Front Side Door Outside Handle Nut (Qty: 2) Tighten: 10 N.m (89 lb in)
2	Front Side Door Outside Handle Assembly Tip: Disconnect the outside handle rod from the lock assembly before removing the handle.

Callout

Component Name

NOTE: Refer to Fastener Notice .

Fastener Tightening Specifications: Refer to Fastener Tightening Specifications .

Preliminary Procedures

Front Side Door Outside Handle Nut (Qty: 2)

Tighten: 10 N.m (89 lb in)

Front Side Door Outside Handle Assembly
Tip: Disconnect the outside handle rod from the lock assembly before removing the handle.
