Electronic Traction Control Switch Replacement

Fig 1: Electronic Traction Control Switch

Courtesy of GENERAL MOTORS CORP.

Callout	Component Name
1	Instrument Panel Accessory Trim Plate Refer to Instrument Panel Accessory Trim Plate Replacement .
2	Inflatable Restraint Indicator Bracket Screw (Qty: 5) NOTE: Refer to Fastener Notice . Tighten:  2 N.m (18 lb in)
3	Inflatable Restraint Indicator Bracket
4	Electronic Traction Control Switch Assembly
