Left Rear of Engine Compartment Components

Left Rear of Engine Compartment Components

Items
1:  B20 Brake Fluid Level Switch B20 Brake Fluid Level Switch
2:  M75 Windshield Wiper Motor M75 Windshield Wiper Motor
3:  K17 Electronic Brake Control Module K17 Electronic Brake Control Module
4:  X50D Fuse Block - Battery X50D Fuse Block - Battery X1X50D Fuse Block - Battery X2X50D Fuse Block - Battery X3X50D Fuse Block - Battery X4 (KL9)X50D Fuse Block - Battery X5X50D Fuse Block - Battery X6X50D Fuse Block - Battery X7 (KL9)X50D Fuse Block - Battery X7 (without KL9)
5:  X50A Fuse Block - Underhood X50A Fuse Block - Underhood X1X50A Fuse Block - Underhood X2X50A Fuse Block - Underhood X3X50A Fuse Block - Underhood X4X50A Fuse Block - Underhood X5X50A Fuse Block - Underhood X6
6:  C1 Battery C1 Battery + (without KL9)C1 Battery - (Battery Negative) (without KL9)C1 Battery - (Body Harness)
7:  B18 Battery Current Sensor B18 Battery Current Sensor (without KL9)
8:  K20 Engine Control Module K20 Engine Control Module X1K20 Engine Control Module X2K20 Engine Control Module X3 (LKW or LTG)K20 Engine Control Module X3 (LUK)
9:  B19B Brake Booster Vacuum Sensor (FX3) B19B Brake Booster Vacuum Sensor

Fig 1: Left Rear of Engine Compartment Components

Courtesy of GENERAL MOTORS COMPANY
