Installation Procedure

    Fig 1: Engine Compression Test Tool
    GM2755435Courtesy of GENERAL MOTORS COMPANY
  1. Remove the suitable engine compression test tool to the spark plug hole.
  2. Install the fuel pump relay.
  3. Install the relay carrier cover.
  4. Install the spark plugs and tighten the spark plug to 20 (14.7 lb ft).
  5. Install the ignition coil cover (2). Refer to Ignition Coil Cover Replacement (LL0) , Ignition Coil Cover Replacement (LFM) .
    6. CAUTION:

    Refer to Fastener Caution .

  6. Tighten the bolts (1) to 10 (89 lb in).
