Multifunction Relay Module Bracket Replacement
WARNING: This page does not describe the selected car, but rather 6 other vehicles, including the 2015 GMC Yukon XL, 2015 GMC Yukon, 2015 Chevrolet Tahoe, 2015 Chevrolet Suburban, and 2015 Cadillac Escalade ESV. However, it is still accessible from the selected car via links, so may be relevant.
| Callout | Component Name |
|---|---|
| Preliminary Procedure Remove the front view camera. Refer to Front View Camera Replacement . |
|
| 1 | Multifunction Relay Module Bracket Procedure Slide the bracket upward to disengage tabs, gently pull from windshield. |
