Installation Procedure

  1. Rear Side Door Inside Handle Cable Replacement  - Install
  2. Rear Side Door Outside Handle Cable Replacement  - Install
  3. Transfer components as necessary.
  4. GM3753753Courtesy of GENERAL MOTORS COMPANY

    Rear Side Door Outside Handle Bracket (1) @ the Rear Side Door Latch (2) - Install

  5. Fig 1: Rear Side Door Latch And Bolts With Tightening Sequence
    GM4845250Courtesy of GENERAL MOTORS COMPANY
    CAUTION:

    Refer to Fastener Caution

    NOTE:

    Install and torque the four latch bolts in proper sequence to prevent damage to the latch mechanism.

    Rear Side Door Latch Bolt (1) - Install and tighten [4x] 11 N.m (97 lb in)

  6. Rear Side Door Locking Rod Knob Replacement  - Install
  7. Rear Side Door Outside Handle Bracket Replacement  - Install
  8. Rear Side Door Window Regulator Replacement - Install
  9. Rear Side Door Window Channel Rear Retainer Replacement - Install
  10. Connect the electrical connector.
  11. Inspect the door latch and outside handle for proper operation before installing the door trim.
  12. Remove the tape from the rear side door window and frame.
