Removal Procedure
WARNING:
When working with any type of glass or sheet metal with exposed or rough edges, wear approved safety glasses and gloves in order to reduce the chance of personal injury.
WARNING:
If a window is cracked but still intact, crisscross the window with masking tape in order to reduce the risk of damage or personal injury.
NOTE:
Use a urethane adhesive systems which meet GM Specification GMW-15672.
- Open the rear compartment lid.
- Cover to protect the following parts from broken glass:
- The defroster outlets and A/C outlets
- The seats and carpeting
- Apply a double layer of masking tape around the perimeter of the painted surfaces.
Using a suitable tool, carefully cut the lace and urethane adhesive bead around the intermediate window (1).
Remove the intermediate windshield (1) and locating pins (2) from the vehicle.
- Leave a base of urethane on the pinchweld flange.
- The only suitable lubrication is clear water.
- Transfer components as necessary.
WARNING:
If broken glass falls into the defroster outlets, it can be blown into the passenger compartment and cause personal injury.
